Iray Nocpix 640 Multi- Function Thermal - Slim- H35
$3,299.99
The new SLIM series from Nocpix provides the best value and features in a compact optic. Focused on versatility and ease of use, SLIM models can be used as either a handheld monocular or a weapon sight. With the included proprietary quick-detach mounting system a hunter can quickly scan and then re-attach the optic to the rifle while maintaining zero. A magnesium alloy body and quiet, soft-touch buttons provide excellent ergonomics in both handheld and weapon-mounted configurations. The included IRB-2 batteries (flat-top 18650 style cell) are easy to swap–letting you stay out longer with the ability to charge through the optic using a magnetic cable. Generous eye relief and a 1024×768 AMOLED display provide a comfortable and highly detailed viewing and hunting experience.
Features
- Ambidextrous one-handed design for easy use as a handheld monocular or weapon sight.
- Recoil-activated video automatically records footage before and after a shot.
- High-contrast 1024×768 AMOLED display provides increased clarity and detail.
- Quick-release dual-throw mount with a magnetic alignment aid provides fast and secure return-to-zero (1-MOA) weapon mounting.
- Uses common 18650 style rechargeable batteries.
- Available in high and standard-resolution models.
- Quick, secure charging via the magnetic charging port.
Specifications
| Resolution | 640 x 512 | Eye Relief | 48 mm |
| Pixel Size | 12 µm | Diopter Range | -5 to +5 |
| Frame Rate | 60 Hz | Onboard Recording | Video and Image |
| Sensor Sensitivity | ≤18 mK | Onboard Storage | 32 GB |
| Image Processing | Reality+ | Wireless Connectivity | Image and Video via App. |
| Core | Nocpix 640 | Data/Power Connector | Magnetic & USB-C |
| Objective Lens | 35 mm f/1.0 | Power Supply | USB-C External, IBP-7 Li-ion Batteries ×2 (4+ Hours Each) |
| Native Magnification | 2x | Start Up Time | <10 Seconds, Instant from Standby |
| Digital Zoom | 4x | Dimensions | 8.50” × 2.99” × 1.81” |
| Field of View | 12.6° × 9.4° | Weight | 18.7 oz. |
| Detection Range | 1,750 yards | Manufacturer's Warranty | 5 Years |
| Display Type | 1.03-inch Large-format AMOLED | Housing Material | Magnesium Alloy |
| Display Resolution | 1024 × 768 | Ingress Protection | IP67 |
| Picture-in-Picture | Yes | Operation Temperature | -4°F~122°F |
| Color Palettes | White Hot, Black Hot, Red Hot, Color, Crimson, Viridian, Violet |
||
